Visiting:Products>MIG Welding Machines>Gas Shielded Types


FY-5500/2E





MIG Semi-automatic Gas Shielded Welding Machine FY-5500/2E

Our MIG welder uses the most advanced INFINEON IGBT inverter with dual full bridge soft switch circuit technology. This is a core technology to take advantage of the inverter power source to realize the soft switching state of no-load, short circuit and load. This decreases switching stress and also increases the reliability of the unit with a logical, dynamic and static performance.
This unit also has the characteristics of Gas Metal Arc Welding (GMAW) and inverter technology with constant voltage and current output. It is mainly used in the welding of ferrous metallic materials such as copper, aluminium, stainless steel, high-carbon steel as well as being extensively used in the welding and field operation of steel construction, oil pipelines, car production, shipyards and machinery manufacturing.











  • Features
  • Specification
  • Optional


※  Voltage auto-detect function.
※  Welding gun test function.
※  Digital display.
※  Multi-bridge rectifier.
※  Wire feeder with four-roll dual drive system.
※  Complete with heated regulator.
※  Adjustable dynamic arc characteristics.
※  Good forming capability and quality weld appearance.
※  Separated wire feeder and welding gun with extendable cable is available as an option.



Technical Data

Input Voltage

Rated Maximum Supply Current

Maximum Effective Supply Current

Output Current/Voltage

No-load Voltage

Duty Cycle

Insulation Grade

Welding Wire

Voltage Regulation Range

Dimensions

Weight

AC380-400V 3-phase 50/60Hz

30A

23.4A

35A/17V - 500A/39V

21-46A

35%

F

Low Carbon Steel Solid Wire Ф0.8-1.2mm

10 steps

880 x 470 x 890mm

108kg

Due to the continuous innovation and upgrade, our products' features may be updated.

Please refer to actual products or contact us for more information.




Details

Pictures are for reference only, please subject to our available products.
